| Supply voltage DC | 24 V |
|---|---|
| Operating current, max | 6 A |
| Rated current | 6 A fixed |
| Voltage type of supply voltage | DC |
| Degree of protection (IP) | IP20 |
| Width | 12.5 mm |
|---|---|
| Height | 98.5 mm |
| Weight per module | Approx. 0.13 lb |
| Terminal wire gauge | Push-in terminal PT10 AWG20… AWG8 (0.5mm² to 10mm²), Push-in terminal PT2.5 AWG24… AWG14 (0.14mm² to 2.5mm²) |
| Depth | 80 mm |
| Termination type | Push-in |
| No of channels | 2 |
|---|---|
| Degree of pollution | 2 |
| Operating temperature | -25 °C |
| Storage temperature | -40 °C |
| Humidity / damp heat | 96 hr / 95% climate class 3K3 |
