| Product Type | 30mm Toggle Switch |
|---|
| Number of switch positions | 2 |
|---|---|
| Terminations with finger safe covers | False |
| Centre mounting, hole diameter | 30.5 mm |
| Operator mechanical design life (cycles, min.) | 200000 |
| Contact block configuration | No contacts |
| Shock | 25 G (contact fragility)/100 G (no damage) |
| Operator function | Up-spring return, down-spring return |
| Suitable for illumination | False |
| Enclosure compatibility (NEMA type) | 1, 4, 12, 13 |
| Operator type | Toggle switch |
| Operating temperature | -25 °C |
|---|---|
| Humidity | 50 to 95% |
| Storage temperature | -40 °C |
| Operator cap/button material | Metal/plastic |
|---|---|
| Operator construction/material | Metal |
| Operator cap type | Lever arm with conical cap |
| Termination style | Screw |
| Operator cap color | Black |
| Certifications | ABS, CCC, CE, CSA, EAC, GOST, UL |
|---|
