| Light Source | Laser |
|---|---|
| Minimum Sensing Distance | 3,400,300 |
| Response Time | 0.70 ms |
| Sensitivity Adjustment | Teach Button |
| Wavelength of the sensor | 650 nm |
|---|---|
| Max. output current | 100 mA |
| Response time | 2 ms |
| Voltage type | DC |
| Type of switching output | PNP |
| Type of electric connection | Connector M12 |
| Sensing mode | Light-/dark switching |
| Current consumption, max | 30 mA |
| Lens material | Acrylic |
| Light source | Laser |
| Operating voltage/mode | DC – light or dark operate complementary |
| Connection type | 4 pin micro (M12) quick disconnect |
| Protection type | Short circuit, reverse polarity, false pulse, overload |
| LED status | Orange ON: light condition (excess gain >2), LO output- ON, DO output- OFF |
| With time function | False |
| With reflector | False |
| Diameter sensor | 16.4 mm |
|---|---|
| Max. switching distance | 300 mm |
| Length of sensor | 79.4 mm |
| Operating distance | 3 mm |
| Sensing mode type | Standard diffuse |
| Vibration | 10…55 Hz, 0.5 mm Alitude, meets or exceeds IEC 600947-5-2 |
| Shock | 30 G with 11 ms pulse duration, meets or exceeds IEC 600947-5-2 |
| Setting procedure | Manual adjustment |
| Material housing | Metal |
|---|---|
| Laser protection class | Class 1 |
| Construction type housing | Cylinder, screw-thread |
| Material of optical surface | Plastic |
| Field of view | 6.6 ° |
|---|---|
| Operating temperature | -25 °C |
| Relative humidity | 5…95% (noncondensing) |
| Ambient light immunity | Incandescent light 5000 lux |
| Peso | 0.081647 kg |
|---|---|
| Dimensiones | 13.41 × 4.39 × 3.4 cm |
| Marcas | Allen-Bradley |
Marca
Rockwell Automation
| Type | Resource | Publication |
|---|---|---|
| General | Product Cutsheet | -- |
| Installation Instructions | 42cm-in001_-en-p | 42CM-IN001 |
|
Product Cutsheet
General
-- |
|
42cm-in001_-en-p
Installation Instructions
42CM-IN001 |
