| Product Family | Series 9000 |
|---|
| Degree of protection (IP) | IP67 |
|---|---|
| Length amplifier | 40 mm |
| Width amplifier | 41.91 mm |
| Height amplifier | 74.93 mm |
| Wave length | 880 nm |
| Sensing mode type | Fiber optic large aperture |
| Sensing distance | Depends on fiber optic cable |
| List of degrees of protection (IP) | IP69K, IP67 |
| Operating environment | IP69K, IP67 with 1200 psi, NEMA 3, 4X, 6P, 12, 13, ECOLAB rated |
| Setting procedure | Manual adjustment |
| Vibration | 10…55 Hz, 1 mm Alitude, meets or exceeds IEC 60947-5-2 |
| Shock | 30 G with 1 ms pulse duration, meets or exceeds IEC 60947-5-2 |
| Voltage type | DC |
|---|---|
| Material housing | Plastic |
| Rated control supply voltage at DC | 10 V |
| Type of switching output | PNP/NPN |
| Type of light | Infrared light |
| Type of electric connection | Connector M12 |
| Current consumption, max | 30 mA |
| Load current | 250mA @ 30V DC |
| Connection type | 4 pin DC micro (M12) QD |
| Operating voltage/mode | DC – NPN and PNP |
| Protection type | Short circuit, reverse polarity, false pulse, overload |
| LED status | Yellow ON: power is on |
| Sensor types | Standard ON/OFF |
| Output function | Selectable light or dark operate |
| Housing material | Valox® |
|---|---|
| With time function | False |
| Construction type housing | Special construction |
| Lens material | Acrylic |
| Operating temperature | -34 °C |
|---|---|
| Relative humidity | 5 % |
| Ambient light immunity | Incandescent light 5000 lux |
| Field of view | Depends on fiber optic cable |
