Name: 440P-MALB22E, Safety Limit Switches, Large Metal IEC, Full Sw Head &amp; Body, Adjustable Roller Lever, 4 Circuits, Conduit Entry, Break Before Make, 2 Norma lly Closed Contacts, 2 Normally Open Contacts, Standard Contacts, -25C Low Temp Limit, 65C High Temp Limit, Spring Return, 1/2" NPT Thread , 30mm Large IEC Style Mounting
SKU: 440P-MALB22E
Availability: OutOfStock

440P-MALB22E, Safety Limit Switches, Large Metal IEC, Full Sw Head & Body, Adjustable Roller Lever, 4 Circuits, Conduit Entry, Break Before Make, 2 Norma lly Closed Contacts, 2 Normally Open Contacts, Standard Contacts, -25C Low Temp Limit, 65C High Temp Limit, Spring Return, 1/2″ NPT Thread , 30mm Large IEC Style Mounting

MXN $6,122.00 - (IVA Incluido) + Envío

Sin existencias

Safety Limit Switches, Large Metal IEC, Full Sw Head & Body, Adjustable Roller Lever, 4 Circuits, Conduit Entry, Break Before Make, 2 Norma lly Closed Contacts, 2 Normally Open Contacts, Standard Contacts, -25C Low Temp Limit, 65C High Temp Limit, Spring Return, 1/2″ NPT Thread , 30mm Large IEC Style Mounting

Categoría: Safety

Etiqueta: Safety

SKU: 440P-MALB22E

Technical Specifications

Electrical

Number of contacts as normally closed contact	2
Number of contacts as normally open contact	2
With status indication	No
Type of electric connection	Other
Utilization category	N600/DC-13
Switching current, min	5 mA @ 5V DC
Auxiliary contacts	1NO (with 2 NC)
Contact current rating (Ie)	6 A @ 120V AC (Ue)
Thermal current (Ith)	10 A
Actuation speed, min	100 mm/min
Actuation speed, max	250 mm/s
Rated impulse withstand voltage	2500 V
Actuation frequency, max	6000 ops/hr
Rated insulation voltage	600V AC

Mechanical

Suitable for safety functions	Yes
Forced opening	Yes
Degree of protection (NEMA)	1
Material housing	Metal
Degree of protection (IP)	IP66
Contact type	Break before make
Enclosure color	Red
Mounting	2 x M5, any position
Body style	30 mm large metal body
Width	31 mm
Height	172 mm
Actuator type	Adjustable roller lever
Mechanical life operations	10000000 operations per hour
Housing material	Die-cast alloy
Connection type	1/2 inch NPT conduit
Construction type housing	Cuboid

Construction

Depth	40 mm
Actuator material	Various polymers and metals

Environmental

Operating temperature	-25 °C
Safety contacts	1 NC snap acting, 2 NC, 3 NC or 4 NC slow acting
Pollution degree	3
Shock	IEC 60068-2-7 (30 Gn 3 pulses per axis)
Vibration	IEC 60068-2-6 (10…55 Hz, 0.35 mm amplitude)

Show More Show Less

Peso	0.519 kg
Dimensiones	17.09 × 7.59 × 4.59 cm
Marcas	Allen-Bradley

Marca

Allen-Bradley
