| Output | 2 OSSD |
|---|
| With approval according to UL | True |
|---|---|
| With approval for TUV | True |
| Performance level according to EN ISO 13849-1 | Level d |
|---|---|
| Mission time | 20 year |
| Hours of operation | 24 h |
| MTTFd | 378 None |
| Days of operation | 365 dbays |
| DC avg. (EN ISO 13849-1) | 97.66 % |
| Category | Up to 3 |
| Performance level | Up to d |
| T cycle | 8/28.8 (h/s) |
| Rated operating frequency | 4 khz |
|---|---|
| Evaluation inputs | One- and two-channel |
| Type of electric connection | Screw connection |
| Power consumption | 2 W |
| Rated control supply voltage Us at DC | 24 V |
| Wire size | 0.2…2.5 mm² (24…14 AWG) |
| Number of outputs, safety related, undelayed, with contact | 0 None |
| Number of outputs, safety related, delayed, with contact | 0 None |
| Number of outputs, signalling function, undelayed, with contact | 0 None |
| Number of outputs, signalling function, delayed, with contact | 0 None |
| Number of outputs, signalling function, undelayed, semiconductors | 1 None |
| Number of outputs, signalling function, delayed, semiconductors | 0 None |
| Voltage type for actuating | DC |
| Suitable for safety functions | True |
| With detachable clamps | True |
| With feedback circuit | True |
| Surge auxillary output current duration, max | 5 ms |
| Surge safety output current duration, max | 5 ms |
| Continuous auxiliary output current | 50 mA |
| Surge auxiliary output current | 700 mA |
| Aggregate current of outputs per module, max | 1.8 A |
| Continuous safety output current, max | 0.5 A |
| Surge safety output current, max | 1.5 A |
| Number of outputs, safety related, undelayed, semiconductor | 2/4 |
| Number of outputs, safety related, delayed, semiconductor | 0/2 |
| Other output | SWS output |
| Operating voltage range | 20.4 |
| Configurable logic | Logic setting 1 – cat 1 stop, logic IN off, Logic setting 2 – cat 1 stop with logic IN, Logic setting 3 – safe limited slow speed, logic IN off, Logic setting 4 – safe limited slow speed with logic IN, Logic setting 5…8 – guard locking with delayed unlo |
| Operating temperature | -5 °C |
|---|---|
| Enclosure protection | IP40 (NEMA 1) |
| Relative humidity | 90% |
| Height | 119.4 mm |
|---|---|
| Width | 22.5 mm |
| Depth | 113.6 mm |
| Vibration | 10…55 Hz, 0.35 mm |
|---|---|
| Shock | Shock proof, operating: 10 G, 16 ms |
| Function rotational speed monitoring | True |
| Function standstill monitoring | True |
