| Detection Width | 87 mm (3.4 in.) Sensing Height |
|---|---|
| Housing Height | 140mm (5.5in) |
| Light Source | Visible Red |
| Sensing Mode | Retroreflective / Diffuse |
| Sensitivity Adjustment | Manually Adjustable |
| Degree of protection (NEMA) | 12 |
|---|---|
| Max. switching distance | 400 mm |
| Width sensor | 32 mm |
| Height of sensor | 140 mm |
| Detection width | 100 mm |
| Vibration | 10…55 Hz, 1.5 mm Alitude, 2 hr, X, Y and Z direction |
| Shock | 500 m/s² 3 times X, Y and Z direction |
| Setting procedure | Manual adjustment |
| Optical axis pitch | 29 mm |
| Degree of protection | IP62 |
| Wavelength of the sensor | 640 nm |
|---|---|
| Max. output current | 50 mA |
| Response time | 120 ms |
| Voltage type | DC |
| Rated control supply voltage at DC | 12 V |
| Type of switching output | PNP/NPN |
| Type of electric connection | Connector M12 |
| Type of light | Infrared light |
| Sensing mode | Light-/dark switching |
| Type of switch function | Progmable/configurable |
| Current consumption, max | 68 mA |
| Lens material | Polycarbonate |
| Light source | Visible red |
| Operating voltage/mode | DC – light or dark operate selectable |
| Output type | Sink (NPN)/source (PNP) output selectable |
| Connection type | DC micro (M12) on pigtail |
| Sensitivity adjustment | Manually adjustable |
| Protection type | Short circuit, Reverse polarity |
| LED status | Orange ON: Output is de-energized |
| Suitable for safety functions | False |
| With time function | False |
| Pre failure notice | False |
| With communication interface analogue | False |
| With communication interface AS-Interface | False |
| With communication interface CANOpen | False |
| With communication interface DeviceNet | False |
| With communication interface Ethernet | False |
| With communication interface INTERBUS | False |
| With communication interface PROFIBUS | False |
| With communication interface RS-232 | False |
| With communication interface RS-422 | False |
| With communication interface RS-485 | False |
| With communication interface SSD | False |
| With communication interface SSI | False |
| With reflector | False |
| Ambient light, max | 10000 lx |
| Status indicator | Green and orange |
| Dielectric strength | 1000V AC @ 1min |
| Output mode | NPN/PNP output selectable, rating: Current 50 mA (30V DC) max. residual voltage 2V or less |
| Material housing | Metal |
|---|---|
| Number of optical axes | 4 |
| Housing material | Aluminium |
| Material of optical surface | Plastic |
| Operating temperature | -10 °C |
|---|---|
| Storage temperature | -25 °C |
| Operating humidity | 35…85% RH |
