| Control Voltage | 24-48V DC / 24-240V 50/60Hz |
|---|---|
| Timing Range | 0.5 s to 10 s |
| Number of outputs, delayed, change-over contact | 1 |
|---|---|
| Voltage type for actuating | AC/DC |
| Rated control supply voltage at AC 50 Hz | 24 |
| Rated control supply voltage at AC 60 Hz | 24 |
| Rated control supply voltage at DC | 24 |
| Type of electric connection | Screw connection |
| Input current | 1 mA |
| Power consumption | 5VA @ 240V AC |
| Switching capacity | Voltage: 440V @ AC |
| Electrical life cycle | 500000 at 6 A/24V DC, resistive |
| Function delay on de-energization | Yes |
| Nominal current | 8 |
|---|---|
| Suitable for DIN rail (top hat rail) mounting | Yes |
| Weight | 100 |
| Shock resistance | 50 g according to IEC 68-2-27 |
| Vibration resistance | 4 g in three axes at 10…500 Hz, test FC according to IEC 60068-2-6 |
| Suitable for front mounting | No |
| With plug-in socket | No |
| Ambient temperature | Storage: -40…85 °C |
|---|---|
| Hazardous location rating | Not for use when harardous location certification is required |
| Mounting | Front mounting: for snap-on mounting on 35 mm DIN rail or screw fixing by adapter and 2 screws (M4 type) |
|---|---|
| Pluggable on auxiliary contact block | No |
