| Number of contacts as change-over contact | 1 |
|---|---|
| Nominal current | 16 A |
| Complete with socket | False |
| With LED indication | False |
| Voltage type for actuating | AC |
| Rated control supply voltage at AC 50 Hz | 120 V |
| Rated control supply voltage at AC 60 Hz | 120 V |
| Type of electric connection | Plug-in connection |
| Rated thermal current (Ith) | 16 A |
| Electrical life cycle | B300, R300, Hp (kW): 6000 minimum |
| With detachable clamps | False |
|---|---|
| With forced-guided contacts | False |
| Degree of protection (IP) | IP20 |
| Shock | Opsal: 15 G |
| Vibration | Opsal: 10…2000 Hz, 0.76 mm (0.03 in) 2.5 G |
| List of degrees of protection (IP) | IP20 with guarded terminal socket |
| Width | 29 mm |
|---|---|
| Height | 39.3 mm |
| Depth | 12.4 mm |
| Contact material | Silver tin oxide (AgSnO2) – maximum duty contact |
| Material of contact surface | Other |
| Operating temperature | -40 °C |
|---|---|
| Storage temperature | -40 °C |
