700-HLT1A2, SPDT Terminal Block 240V AC Relay Pack
USD $59.56 - (IVA Incluido) + Envío
Sin existencias
SPDT Terminal Block 240V AC Relay Pack
Marca:Allen-Bradley
Technical Specifications
Electrical
| Number of contacts as change-over contact | 1 |
|---|---|
| Nominal current | 6 A |
| Complete with socket | Yes |
| With LED indication | Yes |
| Voltage type for actuating | AC |
| Rated control supply voltage at AC 50 Hz | 240 V |
| Rated control supply voltage at AC 60 Hz | 240 V |
| Rated control supply voltage at DC | 240 V |
| Type of electric connection | Screw connection |
| Rated thermal current (Ith) | 0.25 |
| Power consumption | 0.8VA @ AC, 2-poles |
| Electrical life cycle | 6 A resistive: 100000 minimum, 1 A inductive: 200000 minimum @ 24V DC, 1 A inductive: 300000 minimum @ 120V AC |
Mechanical
| With detachable clamps | Yes |
|---|---|
| With forced-guided contacts | No |
| Degree of protection (IP) | IP20 |
Environmental
| Operating temperature | -40 °C |
|---|---|
| Storage temperature | -40 °C |
Construction
| Contact material | Silver tin Ox, AgSnO2 (SPDT) & AgNi 90/10 (DPDT) |
|---|---|
| Material of contact surface | Other |
| Peso | 0.036004 kg |
|---|---|
| Dimensiones | 0.99 × 7.18 × 8.5 cm |
| Marcas | Allen-Bradley |
Marca
Allen-Bradley
Documentation
| RESOURCE | PUBLICATION NUMBER |
|---|---|
| Technical Data | 700-TD552 |
Find all available product literature for this product in the
Literature Library results.
