Technical Specifications
Electrical
| Number of contacts as change-over contact | 2 |
|---|---|
| Nominal current | 8 A |
| Complete with socket | No |
| With LED indication | No |
| Voltage type for actuating | DC |
| Rated control supply voltage at DC | 110 V |
| Type of electric connection | Plug-in connection |
Mechanical
| With detachable clamps | No |
|---|---|
| With forced-guided contacts | Yes |
| Degree of protection (IP) | Other |
| Mechanical life operations | DC coils: 10000000 |
| Shock | Fragility: 15 G |
| Vibration | Fragility: 2.5 G |
| List of degrees of protection (IP) | IP20 with guarded terminal socket |
Environmental
| Operating temperature | -40 °C |
|---|---|
| Storage temperature | -50 °C |
Construction
| Contact material | Silver Nickel + Gold plating (AgNi + Au) |
|---|---|
| Material of contact surface | Other |
