Technical Specifications
Electrical
| Voltage type for actuating | AC |
|---|---|
| Lamp type | LED |
| Illumination lamp type | Red LED |
| Illumination module type | Spring clamp LED |
| Illumination module input voltage | 240V AC (LED) |
Construction
| Contact block mounting style | Latch |
|---|
Mechanical
| Operator type | 22 mm LED module |
|---|---|
| Illumination module termination wire range | #18…14 AWG (0.75…1.5 mm^2) |
| Vibration | 10 G |
| Shock | 100 G |
| Operator mounting hole dimension | 22.5 mm |
| Latch material | Plastic / metal |
| Illumination module termination tightening torque | 6 – 8 lb – in / 0.7 – 0.9 N-m |
Environmental
| Operating temperature | -25 °C |
|---|---|
| Storage temperature | -40 °C |
| Humidity | ≤95% RH from 25…60 °C (77…140 °F) |
Certification
| Certifications | UL,UR, CSA, CCC, CE |
|---|
