Technical Specifications
Electrical
| Number of contacts as normally closed contact | 1 |
|---|---|
| Contact block configuration | 1 NC |
| Contact block type | NC early break |
| Contact block utilization category (AC) | A600, AC 15 – screw termination |
| Contact block utilization category (DC) | Q600, DC-13 – screw termination |
| Contact block operational voltage, max | 600V (A600, Q600) – screw termination |
| Contact block thermal current rating | 10 A |
Construction
| Contact block mounting style | Latch |
|---|---|
| Termination style | Screw |
| Packaging | Standard pack (1 per package) |
Mechanical
| Latch material | Plastic / metal |
|---|---|
| Contact block termination wire range | #18…12 AWG (0.75…2.5 mm^2) |
| Vibration | 10 G |
| Shock | 100 G |
| Operator mounting hole dimension | 22.5 mm |
| Contact block durability | 1.0E7 |
| Contact block termination tightening torque | 6 – 8 lb – in / 0.7 – 0.9 N-m |
Environmental
| Operating temperature | -25 °C |
|---|---|
| Storage temperature | -40 °C |
| Humidity | ≤95% RH from 25…60 °C (77…140 °F) |
Certification
| Certifications | UL,UR, CSA, CCC, CE |
|---|
