| Number of switch positions | 2 |
|---|---|
| Switching function latching | True |
| Material front ring | Metal |
| Colour control element | Black |
| Operator cap color | Black |
| Operator construction/material | Metal |
| Operator cap/button material | Metal |
| Latch material | Metal |
| With front ring | True |
| Type of control element | Short thumb-grip |
| Suitable for illumination | False |
|---|
| Spring-return | False |
|---|---|
| Switch orientation | Standard |
| Packaging | Standard pack (1 per package) |
| Operator type | Selector switch – standard knob |
| Operator function | Maintained, 2 position |
| Enclosure compatibility | IP66, Type 4/13 (round metal operator) |
| Hole diameter | 22.5 mm |
| Vibration | 10 g |
| Shock | 100 g |
| Operator mechanical design life (cycles, min.) | 1000000 |
| Hazardous location rating | False |
|---|---|
| Operating temperature | -25 °C |
| Storage temperature | -40 °C |
| Humidity | ≤95% RH from 25…60 °C (77…140 °F) |
| Certifications | UL,UR, CSA, CCC, CE |
|---|
| Peso | 0.045359 kg |
|---|---|
| Dimensiones | 6.4 × 4.8 × 3.5 cm |
| Marcas | Allen-Bradley |
Marca
Rockwell Automation
| Type | Resource | Publication |
|---|---|---|
| General | Product Cutsheet | -- |
| General | Push my Buttons Podcast | -- |
| User Manual | 800-um001_-en-p | 800-UM001 |
|
Product Cutsheet
General
-- |
|
Push my Buttons Podcast
General
-- |
|
800-um001_-en-p
User Manual
800-UM001 |
