Technical Specifications
Construction
| Material front ring | Plastic |
|---|---|
| Colour lens | Colourless |
| Operator construction/material | Plastic |
| Operator cap type | Diffuse |
| Operator cap/button material | Plastic |
| Operator cap color | Clear |
| Latch material | Plastic |
| With front ring | Yes |
| Construction type lens | Round |
| Operator cap/button shape | Round |
Mechanical
| Packaging | Standard pack (1 per package) |
|---|---|
| Enclosure compatibility | IP69K, IP66, Type 4/4X/13 (800FP – round plastic operator) |
| Hole diameter | 22.5 mm |
| Shock | 100 G |
| Operator type | Pilot light |
| Vibration | 10 G maximum |
Environmental
| Operating temperature | -25 °C |
|---|---|
| Storage temperature | -40 °C |
| Humidity | ≤95% RH from 25…60 °C (77…140 °F) |
Certification
| Certifications | UL,UR, CSA, CCC, CE |
|---|
