Technical Specifications
Electrical
| Suitable for illumination | No |
|---|
Construction
| Operator construction/material | Plastic |
|---|---|
| Operator cap color (lens) | Blue |
| Operator cap/button shape | Round |
| Operator cap/button material | Plastic |
Mechanical
| Operator mechanical design life (cycles, min.) | 1.0E7 |
|---|---|
| Operator cap text/symbol | R |
| Operator function | Reset operator |
| Enclosure compatibility | IP66, Type 4/4X/13 (Round plastic operator) |
| Hole diameter | 22.5 mm |
| Vibration | 10 G |
| Shock | 100 G |
| Operator type | Push button |
Environmental
| Operating temperature | -25 °C |
|---|---|
| Storage temperature | -40 °C |
| Humidity | ≤95% RH from 25…60 °C (77…140 °F) |
Certification
| Certifications | UL,UR, CSA, CCC, CE |
|---|
