Technical Specifications
Mechanical
| Spring-return | No |
|---|---|
| Mounting type | Flush mount |
| Shock | Tested @ 100 G (mechanical durability) |
| Vibration | Endurance: tested @ 10 G, 1.52 mm displacement |
| Tightening torque | 9 lb.in |
| Operating force | Zero |
Construction
| Degree of protection (IP) | IP66 |
|---|---|
| List of degrees of protection (NEMA) | 4, 13 |
| Connection type | Terminal wiring |
| Touch button type | Heavy industrial line |
| Degree of protection (NEMA) | 4 |
| Housing/guard | Valox 357 |
| List of degrees of protection (IP) | IP2X, IP66 |
Environmental
| Operating temperature | -25 °F |
|---|---|
| Storage temperature | -40 °F |
| Humidity | 95% RH from 25…50 °C (77…122 °F) (full operation) |
Accessory
| Gasket | 1/16 inch cork-BUNA-N |
|---|
Electrical
| Input voltage | Relay type: full voltage (800Z-GF): 100…240V AC (+10%, -15%) |
|---|---|
| Electrical life cycle | Relay output 150000 operations @ 5 A inductive, 2.5 A resistive |
| Switching function latching | No |
| OFF-delay, max | 60 ms |
| ON-delay, max | 76 ms |
| Output type | Relay output |
| Wire size | #22…12 AWG (0.5…4 mm²) |
