Technical Specifications
Mechanical
| Outer diameter | 43 mm |
|---|---|
| List of degrees of protection (NEMA) | 4, 4X, 13 |
Construction
| Degree of protection (NEMA) | 13 |
|---|---|
| Lens color | Amber |
| Lamp life rating | Average life under static, no vibration, conditions: 50000 h @ 24V AC/DC |
| Degree of protection (IP) | IP66 |
Electrical
| Voltage type | AC/DC |
|---|---|
| Function | Continuous light |
| Current consumption | Amber LED: 22 mA @ 24V AC/DC |
| Estimated light output | Amber LED: 1793 mcd @ 24V AC/DC |
| Operating voltage at DC | 24 V |
| Lamp type | LED |
| Leakage current impact | All light modules can absorb up to 3 mA of leakage current from solid-state outputs without module activation |
Accessory
| Material | Polycarbonate |
|---|
Environmental
| Operating temperature | -30 °C |
|---|---|
| Storage temperature | -30 °C |
