Technical Specifications
Environmental
| Degree of protection (NEMA) | 4X |
|---|---|
| Degree of protection (IP) | IP65 |
| Operating temperature | -25 °C |
| Storage temperature | -25 °C |
Electrical
| Loudness | 103 dB |
|---|---|
| Type of current | AC/DC |
| Lamp type | LED |
| Nominal voltage | 24 V |
| Sound type | Pulsing: yes |
| Nominal current | 73 mA @ 24V AC/DC, 50/60 Hz |
| Frequency sound signal | 3.3 kHz |
| Supply voltage range | ±10% |
| Sound main frequency | 3300 Hz |
| Turn-ON leakage current | ≥3 mA |
| Sound level, min | <85 dB |
| Sound level adjustment | Stepless |
| Sound selection | Externally by terminal connection |
Construction
| Colour housing | Black |
|---|---|
| Lens color | Red |
| Housing color | Black |
| Type of acoustic signal | Pulse tone/continuous tone |
| Lens material | Polycarbonate |
| Housing material | Polycarbonate, black |
| Terminals | Plug-in terminal block, up to 2.5 mm2 (14 AWG), IP2X |
| Mounting | Central mounting for bore holes 22 mm or 30.5 mm with hole adapter kit |
Mechanical
| Height | 82 mm |
|---|---|
| Weight | 85 g |
| List of degrees of protection (NEMA) | 4, 4X, 13 |
| Size | 65 mm diameter sounder and LED |
| Mounting nut torque | 1.7 Nm |
