| Lens Color | Red |
|---|
| Outer diameter | 70 mm |
|---|---|
| Degree of protection (NEMA) | 4X |
| Degree of protection (IP) | IP65 |
| Recommended wire size | 0.5 mm² |
| Recommended terminal torque | 0.8 Nm |
| Shock | 5 module stack: 35 G (Surface-mount base or 10 cm aluminum pole base) |
| Vibration | 5 module stack: 0.75 G (Surface-mount base or 10 cm aluminum pole base) |
| List of degrees of protection (NEMA) | 4, 4X, 13 |
| Function acoustic | False |
|---|---|
| Rated operating voltage Ue | 120 V |
| Voltage type for actuating | AC |
| Flashing frequency for flashing LED modules | Approximately 1.5 Hz, time On/time OFF = 1:1 |
| Operating voltage | 120V AC (±10%) @ AC, 60 Hz |
| Leakage current impact | All light and sound modules can absorb up to 3 mA of leakage current from solid-state outputs without module activation |
| Lens color | Red |
|---|---|
| Housing color | Black |
| Module type | Flashing LED lA |
| Function flashlight | True |
| Flashing light | True |
| Operating temperature | -25 °C |
|---|---|
| Storage temperature | -40 °C |
| Materials | Surface and vertical-mount pole connection box and magnetic mount housing: Polycarbonate |
|---|
