| Outer diameter | 70 mm |
|---|---|
| Degree of protection (NEMA) | 4X |
| Degree of protection (IP) | IP65 |
| Recommended wire size | 0.5 mm² |
| Recommended terminal torque | 0.8 Nm |
| Shock | 5 module stack: 35 G (surface-mount base or 10 cm aluminum pole base) |
| Vibration | 5 module stack: 0.75 G (surface-mount base or 10 cm aluminum pole base) |
| Rated operating voltage Ue | 24 V |
|---|---|
| Voltage type for actuating | AC/DC |
| Lamp life rating | Level-1 LED module: 10000 h |
| Light output | Level-1 module, Yellow LED: 900…1800 mcd |
| Voltage | 24V AC/DC full voltage |
| Operating voltage | 24V (±10%) @ AC/DC |
| Current consumption | Level-1 module: 42mA @ 12V AC/DC |
| Network option | Standard |
| Leakage current impact | Can absorb up to 3 mA of leakage current from solid-state outputs without module activation. |
| Communication rate options | 125K, 250K, 500K, autobaud |
| Housing color | Black |
|---|---|
| Base type | 10 cm pole mount (includes cap) |
| Level-1 lens color | Red |
| Level-2 lens color | No module |
| Level-3 lens color | No module |
| Level-4 lens color | No module |
| Level-5 lens color | No module |
| Level-5 module type | No module |
| Level-1 module type | Steady LED lA module |
| Level-2 module type | No module |
| Level-3 module type | No module |
| Level-4 module type | No module |
| Function continuous light | True |
| Operating temperature | -25 °C |
|---|---|
| Storage temperature | -40 °C |
| Materials | Surface and vertical-mount pole connection box and magnetic mount housing: Polycarbonate |
|---|
