| Rated voltage | 300 V |
|---|---|
| Rated current In | 3 A |
| Assembly rating | 3A @ 300V |
| Cable rating | 300V |
| With shield connection | False |
|---|---|
| Cable length | 5000 mm |
| Second end termination style | No connector |
| Second end termination type | Cable – IEC standard color code |
| Diameter, approx | Connector: 15 mm |
| Length, approx | Connector: 42 mm |
| Product type feature | Standard- Epoxy coated Zinc for DC micro, AC micro, mini QD with 2-6 pin, Standard-Nickel plated Brass for pico, Standard-Aluminum with clear sealant for mini QD with 7-12 pin |
| Diameter | Cable: 5 mm |
| Material of contact surface | Gold |
| Material housing | Plastic |
| Type of plug-in contact, inner side | Female (bus) |
| Mounting method | Freely positionable |
| Operating temperature | -40 °C |
|---|---|
| Number of poles | 4 |
| Second end conductors | Same as first end |
| First end connector style | Female, straight (internal threads, except mini receptacles) |
| Cable type | PVC cable, yellow, unshielded, 22 AWG |
| Material | Coupling nut: Epoxy-coated Zinc, Connector: molded oil-resistant Polyurethane body, Contact: Gold over Nickel-plated Brass |
