Name: 889D-R4AC-20, DC Micro Cable, Female, Rt Angle (Int Threads), Female, Right Angle (int threa, 4-Pins, Standard Materials, 4-Pins, Cable, No Connector, Cable - IEC Stndrd Color Code, No Connector, Same as First End, PVC Cbl, Yellow, UnShld, 22AWG, PVC Cable, Yellow, 22AWG, Cable - IEC Stndrd Color Code, Standard, 20 m
SKU: 889D-R4AC-20
Availability: InStock

889D-R4AC-20, DC Micro Cable, Female, Rt Angle (Int Threads), Female, Right Angle (int threa, 4-Pins, Standard Materials, 4-Pins, Cable, No Connector, Cable – IEC Stndrd Color Code, No Connector, Same as First End, PVC Cbl, Yellow, UnShld, 22AWG, PVC Cable, Yellow, 22AWG, Cable – IEC Stndrd Color Code, Standard, 20 m

MXN $2,773.00 - (IVA Incluido) + Envío

1 disponibles

DC Micro Cable, Female, Rt Angle (Int Threads), Female, Right Angle (int threa, 4-Pins, Standard Materials, 4-Pins, Cable, No Connector, Cable – IEC Stndrd Color Code, No Connector, Same as First End, PVC Cbl, Yellow, UnShld, 22AWG, PVC Cable, Yellow, 22AWG, Cable – IEC Stndrd Color Code, Standard, 20 m

Comprar Ahora

Categoría: Others

Etiqueta: Others

SKU: 889D-R4AC-20

Technical Specifications

Mechanical

Number of poles	4
Degree of protection (IP), mounted	IP69K
Operating temperature	-20 °C
Number of pins	4-pins
Second end conductors	Same as first end
Enclosure type rating	NEMA 6P, 1200 psi (8270 kPa) washdown, IP69K
First end connector style	Female, right angle (internal threads)
Cable type	Oil-resistant PVC jacket, 18 or 22 AWG conductors, 300V
Material	Coupling nut: Epoxy-coated Zinc, Molded oil-resistant PUR, Contact: Gold over Nickel-plated Brass
Bend radius	10 x diameter

Electrical

Rated voltage	250 V
Rated current In	4 A
Assembly rating	4 A @ 250V
Cable rating	UL AWM style 2661 VW-1 105 °C 300V, CSA AWM A/B I/II 80 °C 300V FT1, UV oil and water resistant

Construction

With shield connection	No
Cable length	20000 mm
Second end termination style	No connector
Second end termination type	Cable – IEC standard color code
Diameter, approx	Connector: 14 mm (0.56 inch) @ straight male
Length, approx	Connector: 50.8 mm (2.0 inch) @ straight male
Height, approx	Connector: 31.8 mm (1.25 inch) @ right angle male
Product type feature	Standard- Epoxy coated Zinc for DC micro,AC micro, mini QD with 2-6 pins, Standard-Nickel plated Brass for pico, Standard-Aluminum with clear sealant for mini QD with 7-12 pins
Diameter	2 core cable: 5 mm (0.21 inch), 3 core cable: 5 mm (0.21 inch), 4 core cable: 5 mm (0.21 inch), 5 core cable: 6.5 mm (0.25 inch), 4 core cable (18 AWG): 6.5 mm (0.25 inch)
Material of contact surface	Gold
Material housing	Plastic
Type of plug-in contact, inner side	Female (bus)
Mounting method	Freely positionable

Show More Show Less

Peso	0.91 kg
Dimensiones	23.06 × 23.95 × 3.42 cm
Marcas	Allen-Bradley

Marca

Allen-Bradley

Documentation

RESOURCE	PUBLICATION NUMBER
Technical Data	889-TD002

Find all available product literature for this product in the Literature Library results.
