9001KP3, Pilot light head, Harmony 9001K, metal, without cap, 30mm, 208-220V

MXN $1,119.00 - (IVA Incluido) + Envío

13 disponibles
Comprar Ahora
SKU: 9001KP3

Pilot light head, Harmony 9001K, metal, without cap, 30mm, 208-220V

9001KP3

Main
Range of Product Harmony 9001K
Product or Component Type Head for pilot light
Device short name K
Complementary
Bezel material Metal
Mounting diameter 1.2 in (30 mm)
Cap/operator or lens colour Without cap
Bulb base BA 9s
Light block supply Via transformer 208 V AC 50/60 Hz
Via transformer 220 V AC 50/60 Hz
Shape of screw head Round
Light source Incandescent bulb
Operating Mode Normal
[Us] rated supply voltage 208…220 V
Light block supply Via integral transformer
Supply frequency 50…60 Hz
Size 30 mm
Environment
Product Certifications CSA LR25490 class 3211 03
CE
UL listed file E42259 CCN NKCR
NEMA degree of protection NEMA 1/2/3/3R/4/6/12/13
Ordering and shipping details
Category US10CS121426
Discount Schedule 0CS1
GTIN 785901005698
Returnability Yes
Country of origin MX
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 5.080 in (12.903 cm)
Package 1 Width 2.0000000000 in (5.08 cm)
Package 1 Length 12.903 in (32.774 cm)
Package 1 Weight 7.84 oz (222.26 g)
Contractual warranty
Warranty 18 months
Peso 5 kg
Dimensiones 15 × 15 × 15 cm
Marcas

Schneider Electric

Marca

Schneider Electric

Product Datasheet
Instruction Sheet
Brochure
Technical Drawing
