Push to test pilot light, Harmony 9001K, metal, polycarbonate, fresnel lens, green, 30mm, 110…120V
9001KT1G31
| Range of Product | Harmony 9001K |
|---|---|
| Product or Component Type | Push-to-test pilot light |
| Device short name | K |
| Bezel material | Metal |
|---|---|
| Mounting diameter | 1.2 in (30 mm) |
| Lens type | Fresnel plastic |
| Cap/operator or lens colour | Green |
| Bulb base | BA 9s |
| Light block supply | Via transformer 110 V AC 50/60 Hz Via transformer 120 V AC 50/60 Hz |
| Shape of screw head | Round |
| Light source | Incandescent bulb |
| Operating Mode | Push-to-test |
| Lens type | Fresnel |
| [Us] rated supply voltage | 110…120 V |
| Light block supply | Via integral transformer |
| Contacts type and composition | 1 C/O |
| Supply frequency | 50…60 Hz |
| Lens material | Polycarbonate |
| Size | 30 mm |
| Product Certifications | CSA LR25490 class 3211 03 CE UL listed file E42259 CCN NKCR |
|---|---|
| NEMA degree of protection | NEMA 1/2/3/3R/4/6/12/13 |
| Category | US10CS121426 |
|---|---|
| Discount Schedule | 0CS1 |
| GTIN | 785901035763 |
| Returnability | Yes |
| Country of origin | US |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 2.200 in (5.588 cm) |
| Package 1 Width | 4.50 in (11.43 cm) |
| Package 1 Length | 2.0000000000 in (5.08 cm) |
| Package 1 Weight | 9.280 oz (263.084 g) |
| Warranty | 18 months |
|---|
