Circuit breaker, FA, 240V, 15A, 1 pole
FAL12015
| Product or Component Type | Circuit breaker |
|---|---|
| Trip Unit Technology | Thermal-magnetic |
| Line Rated Current | 15 A |
|---|---|
| Number of Poles | 1P |
| Breaking capacity code | A |
| Mounting Mode | Unit mount |
| Magnetic Hold Current | 275 A |
| Magnetic Tripping Current | 600 A |
| Electrical connection | Lugs, load Lugs, line |
| Terminal identifier | AL50FA |
| Phase connection | ABC |
| Height | 6.4 in (162.6 mm) |
| Width | 1.5 in (38.1 mm) |
| Depth | 4.13 in (104.90 mm) |
| Certifications | CSA UL Listed |
|---|
| Category | US10DE200901 |
|---|---|
| Discount Schedule | 0DE2 |
| GTIN | 3606487251224 |
| Returnability | No |
| Country of origin | MX |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 2.09 in (5.3 cm) |
| Package 1 Width | 5.0000000000 in (12.7 cm) |
| Package 1 Length | 6.9 in (17.5 cm) |
| Package 1 Weight | 28.8 oz (816.0 g) |
| Unit Type of Package 2 | PAL |
| Number of Units in Package 2 | 1357 |
| Package 2 Height | 40.0000000000 in (101.6 cm) |
| Package 2 Width | 40.0000000000 in (101.6 cm) |
| Package 2 Length | 48.0000000000 in (121.92 cm) |
| Package 2 Weight | 2443.00 lb(US) (1108.125 kg) |
| Warranty | 18 months |
|---|
