Name: LB1LD03M61, Protection module, TeSys integral 63, 3P, AC-43, 45 to 63A, 690VAC, thermal-magnetic
SKU: LB1LD03M61
Availability: InStock

LB1LD03M61, Protection module, TeSys integral 63, 3P, AC-43, 45 to 63A, 690VAC, thermal-magnetic

MXN $27,758.00 - (IVA Incluido) + Envío

1 disponibles

TeSys Integral thermal magnetic protection module, for mounting on contactor breakers LD1LD, LD4LD, LD5LD. With an adjustable thermal setting range Irth 45-63A, a tripping class 20, and a magnetic protection range 380-760A (6 to 12 Irth max), it protects motors 25 to 33kW@400V AC-43 for normal starting applications. It ensures phase imbalance protection and compensation of the thermal protection from -20 to 60°C. Manual reset is done by the control knob of the contactor breaker, remote reset requires an additional reset module mounted on the contactor breaker (to be ordered separately). Multi standards certified (IEC, UL, CSA, Marine), Green Premium compliant (RoHS/REACh).

Comprar Ahora

Main
Range	TeSys
Device short name	LB1LD
Range compatibility	TeSys TeSys Integral contactor breaker
Product or Component Type	Protection module
Poles description	3P
Utilisation category	AC-43
[Ue] rated operational voltage	690 V AC
thermal protection adjustment range	45…63 A
Magnetic tripping current	380…760 A
Trip unit technology	Thermal-magnetic
Protection Type	Phase imbalance
Thermal overload class	Class 20

Complementary
Motor power kW	15 kW 220…240 V AC 50/60 Hz 33 kW 400…415 V AC 50/60 Hz 33 kW 440 V AC 50/60 Hz 40 kW 480…525 V AC 50/60 Hz 55 kW 600…690 V AC 50/60 Hz
Net Weight	1.72 lb(US) (0.78 kg)

Environment
Standards	NF C 63-650
Protective treatment	TH
IP degree of protection	IP20 B IEC 60144 IP20 B IEC 60529
Ambient air temperature for operation	-4…140 °F (-20…60 °C)

Ordering and shipping details
Category	US10I1122384
Discount Schedule	0I11
GTIN	3389110180701
Returnability	No
Country of origin	FR

Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	4.13 in (10.5 cm)
Package 1 Width	4.72 in (12.0 cm)
Package 1 Length	7.09 in (18.0 cm)
Package 1 Weight	2.25 lb(US) (1.02 kg)
Unit Type of Package 2	S03
Number of Units in Package 2	8
Package 2 Height	11.81 in (30.0 cm)
Package 2 Width	11.81 in (30.0 cm)
Package 2 Length	15.75 in (40.0 cm)
Package 2 Weight	19.251 lb(US) (8.732 kg)
