| product line | QO |
|---|---|
| product type | Bar |
| Number of connectors | 9 |
|---|---|
| wire size | AWG 14…AWG 10 copper AWG 12…AWG 10 aluminium AWG 8 aluminium/copper AWG 6…AWG 4 aluminium/copper AWG 14…AWG 12 |
| Provided equipment | 2 screw |
| Bar length | 3.8 in (96 mm) |
| Maximum length of segment | 3.1 in (80 mm) |
| Device mounting | Direct mounting back of enclosure |
| Height | 0.437 in (11.100 mm) |
| Depth | 0.312 in (7.925 mm) |
| Tightening torque | 20 lb.in, AWG 14…AWG 10, copper 20 lb.in, AWG 12…AWG 10, aluminium 35 lb.in, AWG 6…AWG 4 |
| Category | US1DE3A00102 |
|---|---|
| Discount Schedule | DE3A |
| GTIN | 785901026396 |
| Returnability | Yes |
| Country of origin | US |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 0.30 in (0.762 cm) |
| Package 1 Width | 0.85 in (2.159 cm) |
| Package 1 Length | 3.80 in (9.652 cm) |
| Package 1 Weight | 1.600 oz (45.359 g) |
| Unit Type of Package 2 | CAR |
| Number of Units in Package 2 | 10 |
| Package 2 Height | 4.00 in (10.16 cm) |
| Package 2 Width | 6.50 in (16.51 cm) |
| Package 2 Length | 7.10 in (18.034 cm) |
| Package 2 Weight | 19.360 oz (548.847 g) |
| Warranty | 18 months |
|---|
