standard power distribution kit STB – 115..230 V AC
STBPDT2100K
| Range of Product | Modicon STB distributed I/O solution |
|---|---|
| Product or Component Type | Standard power distribution kit |
| Kit composition | STBPDT2100 module STBXBA2200 base STBXTS2130, spring type connectors STBXTS1130, screw type connectors |
|---|---|
| [Us] rated supply voltage | 115…230 V |
| Supply circuit type | AC |
| Supply frequency | 50…60 Hz |
| Power supply output current | 0…10 A 86.0000000000 °F (30 °C) output circuit) 0…2.5 A 140.0000000000 °F (60 °C) input circuit) 0…5 A 86.0000000000 °F (30 °C) input circuit) 0…5 A 140.0000000000 °F (60 °C) output circuit) |
| Voltage range | 85…265 V AC sensor/actuator bus |
| Hot swapping fallback | Hot swapping illegal |
| Protection type | Built-in overcurrent protection, 10 A time-lag output circuit Built-in overcurrent protection, 5 A time-lag input circuit |
| Permissible current | 30 A for 2 minutes grounding terminal |
| Voltage detection threshold | < 50 V +/-5 AC IN/OUT LED non lit > 70 V +/-5 AC IN/OUT LED lit |
| Product Compatibility | Mounting base STBXBA2200 |
| marking | CE |
| Overvoltage category | II |
| Status LED | 1 LED (Green) actuator bus power supply (OUT) 1 LED (Green) sensor bus power supply (IN) |
| Depth | 2.6 in (65.1 mm) |
| Height | 0.7 in (18.4 mm) |
| Width | 4.9 in (125 mm) |
| Net Weight | 0.284 lb(US) (0.129 kg) |
| Product Certifications | CSA FM Class 1 Division 2 UL |
|---|---|
| Pollution degree | 2 IEC 60664-1 |
| Operating altitude | <= 6561.68 ft (2000 m) |
| IP degree of protection | IP20 conforming to EN 61131-2 class 1 |
| Ambient air temperature for operation | 32.0000000000…140.0000000000 °F (0…60 °C) without) |
| Ambient Air Temperature for Storage | -40.0000000000…185.0000000000 °F (-40…85 °C) |
| Relative humidity | 95 % 140.0000000000 °F (60 °C) without condensation |
| Vibration resistance | +/-0.35 mm 10…58 Hz 3 gn 58…150 Hz 35 x 7.5 mm symmetrical DIN rail 5 gn 58…150 Hz 35 x 15 mm symmetrical DIN rail |
| Shock resistance | 30 gn 11 ms IEC 88 reference 2-27 |
| Category | US1PC3218215 |
|---|---|
| Discount Schedule | PC32 |
| GTIN | 3595863949186 |
| Returnability | Yes |
| Country of origin | US |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 1.06 in (2.7 cm) |
| Package 1 Width | 3.4 in (8.6 cm) |
| Package 1 Length | 5.5 in (14.0 cm) |
| Package 1 Weight | 5.1 oz (146.0 g) |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 24 |
| Package 2 Height | 5.9 in (15.0 cm) |
| Package 2 Width | 11.8 in (30.0 cm) |
| Package 2 Length | 15.7 in (40.0 cm) |
| Package 2 Weight | 8.66 lb(US) (3.93 kg) |
| Unit Type of Package 3 | PAL |
| Number of Units in Package 3 | 384 |
| Package 3 Height | 23.6 in (60.0 cm) |
| Package 3 Width | 31.5 in (80.0 cm) |
| Package 3 Length | 151.2 in (384.0 cm) |
| Package 3 Weight | 123.600 lb(US) (56.064 kg) |
| Warranty | 18 months |
|---|
