XVBC21A, Base unit with cover, Harmony XVB Universal, side cable entry, plastic, black, 70mm, AS-Interface connection
USD $452.93 - (IVA Incluido) + Envío
9 disponibles
This base unit is designed to be fitted with indicator bank to create complete tower light and allow clear display of the status of your machines. It is made of glass reinforced polyamide material and it allows the cable to entry from the side. It complies with EN/IEC 60947-5-1, EN/IEC 60068-2-27, UL 508, CSA, AS-Interface No 25701 standards with NEMA 4X protection.
Marca:Schneider Electric
Base unit with cover, Harmony XVB Universal, side cable entry, plastic, black, 70mm, AS-Interface connection
XVBC21A
| Range of Product | Harmony XVB Universal |
|---|---|
| Product or Component Type | Base unit with cover |
| Component name | XVBC |
| Range Compatibility | AS-Interface cabling system |
|---|---|
| Material | Glass reinforced polyamide: base unit Polycarbonate: cover unit |
| Mounting diameter | 2.8 in (70 mm) |
| [Us] rated supply voltage | External 19.2…30 V AS-Interface line 24…31.6 V |
| Current consumption | 250 mA under load via AS-Interface line 30 mA under load external 30 mA no load |
| Actuator sensor interface profile [AS-i] | S.7.F |
| Electrical connection | 1 connector M12 AS-Interface line |
| Cable entry | Side entry |
| Assembly style | Customer assembly, up to 5 units |
| [Ui] rated insulation voltage | 250 V IEC 60947-1 |
| [Uimp] rated impulse withstand voltage | 4 kV IEC 60947-1 |
| Terminals description ISO n°1 | (COM-5)PW (COM-1)PW (COM-4)PW (COM-3)PW (GND)GROUND (COM-2)PW |
| Net Weight | 0.42 lb(US) (0.19 kg) |
| Product Certifications | AS-Interface No 25701 CSA |
|---|---|
| Standards | EN/IEC 60947-5-1 |
| protective treatment | TC |
| Ambient Air Temperature for Storage | -4…158 °F (-20…70 °C) |
| Ambient Air Temperature for Operation | 14…122 °F (-10…50 °C) |
| Shock resistance | 25 gn IEC 60068-2-27 |
| Vibration resistance | 5 gn IEC 60068-2-6 |
| Overvoltage category | Class I IEC 60536 |
| IP degree of protection | IP65 conforming to IEC 60529 |
| NEMA degree of protection | NEMA 4X UL 508 indoor) |
| Category | US1SPX218325 |
|---|---|
| Discount Schedule | SPX2 |
| GTIN | 3389110845044 |
| Returnability | Yes |
| Country of origin | FR |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 3.6 in (9.2 cm) |
| Package 1 Width | 3.07 in (7.8 cm) |
| Package 1 Length | 3.07 in (7.8 cm) |
| Package 1 Weight | 8.4 oz (238.0 g) |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 36 |
| Package 2 Height | 11.8 in (30.0 cm) |
| Package 2 Width | 11.8 in (30.0 cm) |
| Package 2 Length | 15.7 in (40.0 cm) |
| Package 2 Weight | 20.016 lb(US) (9.079 kg) |
| Warranty | 18 months |
|---|
| Peso | 0.238 kg |
|---|---|
| Dimensiones | 7.8 × 7.8 × 9.2 cm |
| Marcas | Schneider Electric |
