Modular tower light, Harmony XVU, audible unit, black, 60mm, buzzer, 24V AC DC
XVUC9S
| Range of Product | Harmony XVU |
|---|---|
| Product or Component Type | Modular tower light |
| Beacon or indicator bank unit type | Buzzer unit |
| Mounting diameter | 2.4 in (60 mm) |
| Component name | XVU |
| Housing Colour | Black |
| Signalling type | Continuous or intermittent buzzer |
|---|---|
| Material | PBT (polybutylene terephthalate) V-0 UL 94 ABS (acrylonitrile butadiene-styrene) V-0 UL 94 PC (polycarbonate) V-0 UL 94 |
| Localisation on device | Top |
| Assembly style | Customer assembly |
| [Us] rated supply voltage | 24 V AC/DC |
| Maximum power dissipation in W | 1.7 W |
| Acoustic level | 85 dB 1 m |
| Sound frequency | 2635 Hz |
| Current consumption | <= 70 mA |
| Length | 2.3 in (58 mm) |
| Net Weight | 0.170 lb(US) (0.077 kg) |
| Product Certifications | UL CE CSA |
|---|---|
| Ambient Air Temperature for Storage | -40.0000000000…158.0000000000 °F (-40…70 °C) |
| Ambient Air Temperature for Operation | -13.0000000000…122.0000000000 °F (-25…50 °C) |
| IP degree of protection | IP54 |
| Category | US100XV22618 |
|---|---|
| Discount Schedule | 00XV |
| GTIN | 3606480555879 |
| Returnability | Yes |
| Country of origin | ID |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 3.5 in (9 cm) |
| Package 1 Width | 5.2 in (13.3 cm) |
| Package 1 Length | 3.6 in (9.1 cm) |
| Package 1 Weight | 6.07 oz (172 g) |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 24 |
| Package 2 Height | 11.8 in (30 cm) |
| Package 2 Width | 11.8 in (30 cm) |
| Package 2 Length | 15.7 in (40 cm) |
| Package 2 Weight | 11.001 lb(US) (4.99 kg) |
| Unit Type of Package 3 | PAL |
| Number of Units in Package 3 | 192 |
| Package 3 Height | 27.6 in (70 cm) |
| Package 3 Width | 31.5 in (80 cm) |
| Package 3 Length | 23.6 in (60 cm) |
| Package 3 Weight | 87.48 lb(US) (39.68 kg) |
