2080-OF2, Micro800 2 Point Analog Output Plug-In

MXN $5,859.00 - (IVA Incluido) + Envío

19 disponibles

Micro800 2 Point Analog Output Plug-In

Comprar Ahora
SKU: 2080-OF2

Technical Specifications

Electrical

Number of analogue outputs 2
Resolution of the analogue outputs 12 Bit
Input, current No
Input, voltage No
Input, resistor No
Input, resistance thermometer No
Input, thermocouple No
Input signal, configurable No
Output, current Yes
Output, voltage Yes
Output signal configurable Yes
Analogue inputs configurable No
Analogue outputs configurable Yes
Type of electric connection Screw connection
Channel to channel isolation Non-isolation
Capacitive load, max 0.1 μF @ voltage outputs
Inductive load, max 0.01 mH @ current outputs
Input group to bus isolation Non-isolation
Wire size Solid: 0.14 mm2 (26 AWG)…1.5 mm2 (16 AWG) @ Rated @ 90 °C (194 °F) insulation maximum, Stranded: 0.14 mm2 (26 AWG)…1.0 mm2 (18 AWG) @ Rated @ 90 °C (194 °F) insulation maximum
Suitable for safety functions No
SIL according to IEC 61508 None
Step response to 63% 5 ms
Recommended maximum shielded cable length 10 m
Current load on voltage output, max 10 mA
D/A Conversion rate (all channels), max 2.5 ms
Open and short-circuit protection Yes
Output overvoltage protection Yes
Voltage ranges 0 V
Current range 0 mA
Output count range 0 to 65535
Overall accuracy Voltage terminal: ±1% full scale @ 25°C, Current terminal: ±1% full scale @ 25°C
Output error Voltage: ±1.5% @ over full temperature range, -20…65°C (-4…149°F), Current: ±2.0% @ over full temperature range, -20…65°C (-4…149°F)

Environmental

Surrounding air temperature, max 65 °C
North American temperature code T4
Power consumption <60 mA @ 24V
Emissions CISPR 11 (IEC 61000-6-4): Class A
ESD immunity IEC 61000-4-2: 6 kV contact discharges, 8 kV air discharges
EFT/B immunity IEC 61000-4-4: ±2 kV @ 5 kHz on shielded ports
Relative humidity IEC 60068-2-30 (Test Db, unpackaged damp heat), 5…95% noncondensing
Conducted RF immunity IEC 61000-4-6, 10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz
Surge transient immunity IEC 61000-4-5: ±2 kV line-earth(CM) on shielded ports
Operating temperature -20…65 °C (-4…149 °F): IEC 60068-2-1 (Test Ad, Operating Cold), IEC 60068-2-2 (Test Bd, operating dry heat), IEC 60068-2-14 (Test Nb, operating thermal shock)
Radiated RF immunity IEC 61000-4-3: 10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz, 10V/m with 200 Hz 50% pulse 100% AM @ 900 MHz, 10V/m with 200 Hz 50% pulse 100% AM @ 1890 MHz, 10V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz,
Operating altitude 2000 m
Nonoperating temperature -40…85 °C (-40…185 °F), IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold), IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat), IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock)

Output Specifications

Load range on voltage output > 1k Ω @ 10V DC
Non-linearity ±0.1% @ in percent full scale
Resistive load on current output 0…500 Ω (includes wire resistance)

General Specifications

Repeatability ±0.1% @ in percent full scale

Mechanical

Vibration IEC 60068-2-6 (Test Fc, operating), 2 G @ 10…500 Hz
Shock IEC 60068-2-27 (Test Ea, unpackaged shock): DIN rail mount: 25 g, nonoperating, Panel Mount: 35 g nonoperating
Mounting torque 0.2 Nm
Terminal screw torque 0.22…0.25 Nm (1.95…2.21 lb-in) (using a 2.5 mm (0.10 in.) flat-blade screwdriver)

Certification

Explosion safety category for gas None
Explosion safety category for dust None
Peso 0.045359 kg
Dimensiones 9.6 × 6.19 × 5.89 cm
Marcas

Allen-Bradley

Marca

Allen-Bradley

Documentation

RESOURCE PUBLICATION NUMBER
User Manual 2080-UM004
