700-HK32Z24-3-4, GP Slim Line Relay, 24V DC, Standard Contacts, 2 Changeover Contact(DPDT)8A, Psh-to-Test & Mnl Ovrrd Funct.
MXN $925.00 - (IVA Incluido) + Envío
154 disponibles
GP Slim Line Relay, 24V DC, Standard Contacts, 2 Changeover Contact(DPDT)8A, Psh-to-Test & Mnl Ovrrd Funct.
Marca:Allen-Bradley
Technical Specifications
Electrical
| Number of contacts as change-over contact | 2 |
|---|---|
| Nominal current | 8 A |
| Complete with socket | No |
| With LED indication | Yes |
| Voltage type for actuating | DC |
| Rated control supply voltage at DC | 24 V |
| Type of electric connection | Plug-in connection |
| Rated thermal current (Ith) | 0.333333333333333 |
| Electrical life cycle | B300, R300, Hp (kW): 6000 minimum |
Mechanical
| With detachable clamps | No |
|---|---|
| With forced-guided contacts | No |
| Degree of protection (IP) | IP20 |
| Shock | Operational: 15 G |
| Vibration | Operational: 10…2000 Hz, 0.76 mm (0.03 inch) 2.5 G |
| List of degrees of protection (IP) | IP20 with guarded terminal socket |
Construction
| Width | 29 mm |
|---|---|
| Height | 39.3 mm |
| Depth | 12.4 mm |
| Contact material | Silver Nickel (AgNi) |
| Material of contact surface | Other |
Environmental
| Operating temperature | -40 °C |
|---|---|
| Storage temperature | -40 °C |
| Peso | 0.02268 kg |
|---|---|
| Dimensiones | 4.82 × 3.55 × 1.65 cm |
| Marcas | Allen-Bradley |
Marca
Allen-Bradley
Documentation
| RESOURCE | PUBLICATION NUMBER |
|---|---|
| Technical Data | 700-TD552 |
Find all available product literature for this product in the
Literature Library results.
