700-HLS1U1-EX, 110/125 V AC/DC GP Terminal Block Relay
MXN $1,916.20 - (IVA Incluido) + Envío
15 disponibles
110/125 V AC/DC GP Terminal Block Relay
Marca:Rockwell Automation
| Switching at zero-crossing | True |
|---|---|
| Height | 76 mm |
| Width | 88 mm |
| Depth | 6.2 mm |
| Voltage type for actuating | AC/DC |
|---|---|
| Rated control supply voltage at AC 50 Hz | 110 V |
| Rated control supply voltage at AC 60 Hz | 110 V |
| Rated control supply voltage at DC | 125 V |
| Rated thermal current (Ith) | DC output: 2 A |
| Power consumption | 0.2 W ±10% @ DC output |
| Leakage current | 100 µA maximum @ 24V |
| Degree of protection | IP20 |
| Operating temperature | -20 °C |
|---|---|
| Storage temperature | -40 °C |
| Hazardous location rating | Hazardous location certification |
|---|
| Peso | 0.024948 kg |
|---|---|
| Dimensiones | 7.62 × 8.89 × 0.76 cm |
| Marcas | Allen-Bradley |
Marca
Rockwell Automation
| Type | Resource | Publication |
|---|---|---|
| General | Product Cutsheet | -- |
| General | Short Circuit Ratings Data Sheet | -- |
| General | 3D Darwing (PDF) | -- |
| Technical Data | 700-td552_-en-p | 700-TD552 |
|
Product Cutsheet
General
-- |
|
Short Circuit Ratings Data Sheet
General
-- |
|
3D Darwing (PDF)
General
-- |
|
700-td552_-en-p
Technical Data
700-TD552 |
