855T-B24TA3, Sound Module 70 mm Stack Lights
MXN $4,945.00 - (IVA Incluido) + Envío
1 disponibles
Sound Module 70 mm Stack Lights
Marca:Allen-Bradley
| Product Family | Sound Module |
|---|
| Operating voltage at DC | 24 V |
|---|---|
| Voltage type | AC/DC |
| Operating voltage | 24V AC/DC (±10%) |
| Current consumption | 45mA @ 24V AC/DC |
| Lamp life rating | Sound modules: 20000 h |
| Leakage current impact | All sound modules can absorb up to 3 mA of leakage current from solid-state outputs without module activation |
| Degree of protection (NEMA) | 4X |
|---|---|
| Tone adjustable | True |
| Degree of protection (IP) | IP65 |
| Colour | Black |
| Function | Continuous tone/pulse tone |
| Outer diameter | 69.5 mm |
|---|---|
| Decibel rating | High 107 dB/low 95 dB, selectable via DIP switch |
| Module type | Dual-circuit piezo-style module with continuous or pulsing tone (modified by energizing one or two circuits of sound modules), Type 4/4X/13, Volume 107 dB or 92 dB @ 1 m |
| Recommended terminal torque | 0.8 Nm |
| Recommended wire size | 0.5 mm² |
| Operating temperature | -25 °C |
|---|---|
| Storage temperature | -40 °C |
| List of degrees of protection (NEMA) | 4, 4X, 13 |
| Materials | Rubber seals and gaskets: Nitrile rubber |
|---|
| Peso | 0.09979 kg |
|---|---|
| Dimensiones | 7.62 × 8.25 × 7.62 cm |
| Marcas | Allen-Bradley |
Marca
Allen-Bradley
| Type | Resource | Publication |
|---|---|---|
| Installation Instructions | 931-in009_-mu-e | 931-IN009 |
| Technical Data | 855-td001_-en-p | 855-TD001 |
