Panelboard interior, NQ, main lugs, 100A, Cu bus, 18 pole spaces, 3 phase, 4 wire, 240VAC, 48VDC
NQ418L1C
| Panelboard Type | Main lugs |
|---|---|
| Product or Component Type | Interiors |
| Branch Circuit Breaker Type | QOB QOB-VH QHB |
| Busbar Material | Copper |
| Number of spaces | 18 |
|---|---|
| Enclosure Nominal Height | 26 in (660.4 mm) |
| Enclosure Nominal Width | 20 in (508.0000000000 mm) |
| Enclosure Nominal Depth | 5.75 in (146.05 mm) NEMA 1 6.5 in (165.1 mm) NEMA 3R/5/12 |
| Line Rated Current | 100 A |
| [Iu] rated interrupted current | 10 kA 22 kA 65 kA |
| Number of Phases | 3 phase 4 wires |
| Voltage Rating | 240 V AC 48 V DC |
| Connections – terminals | Lug line AWG 6…AWG 2/0 aluminium Lug neutral AWG 6…AWG 2/0 aluminium |
| Tightening torque | 40.005…50.007 lbf.in (4.52…5.65 N.m) 0.02…0.10 in² (13.30…67.43 mm²) (AWG 6…AWG 2/0) 100.01 lbf.in (11.3 N.m) 0.02…0.10 in² (13.30…67.43 mm²) (AWG 6…AWG 2/0) 274.99 lbf.in (31.07 N.m) 0.02…0.3 in² (13.30…177.3 mm²) (AWG 6…350 kcmil) 274.99 lbf.in (31.07 N.m) 0.02…0.2 in² (13.30…126.7 mm²) (AWG 6…250 kcmil) 274.99 lbf.in (31.07 N.m) 0.2…0.2 in² (107.2…152 mm²) (AWG 4…300 kcmil) |
| Height | 27 in (685.8 mm) |
| Width | 10.44 in (265.18 mm) |
| Net Weight | 12.50 lb(US) (5.67 kg) |
| Standards | UL CSA |
|---|
| Category | US1PE1A09151 |
|---|---|
| Discount Schedule | PE1A |
| GTIN | 785901502173 |
| Returnability | Yes |
| Country of origin | MX |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 6.3 in (16.0 cm) |
| Package 1 Width | 14.2 in (36.0 cm) |
| Package 1 Length | 26.8 in (68.0 cm) |
| Package 1 Weight | 14.751 lb(US) (6.691 kg) |
| Unit Type of Package 2 | PAL |
| Number of Units in Package 2 | 24 |
| Package 2 Height | 42.50 in (107.95 cm) |
| Package 2 Width | 40.0000000000 in (101.6 cm) |
| Package 2 Length | 48.0000000000 in (121.92 cm) |
| Package 2 Weight | 366.0007 lb(US) (166.015 kg) |
| Warranty | 18 months |
|---|
