NQ442L4C, Panelboard interior, NQ, main lugs, 400A, Cu bus, 42 pole spaces, 3 phase, 4 wire, 240VAC, 48VDC
MXN $24,604.00 - (IVA Incluido) + Envío
69 disponibles
This Schneider Electric OsiSense electronic pressure switch has a 4 digit 7-segment display, hysteresis switching mode. It has a pressure rating of -1 bar. It has a supply voltage of 24Vdc and 2 x solid state outputs (pnp). 0High accuracy for more stable control on your critical processes. Simple reading of current value and threshold with clear LED display. 10 million cycles mechanical durability for minimum required maintenance on your pressurized fluid circuits.
Marca:Schneider Electric
Panelboard interior, NQ, main lugs, 400A, Cu bus, 42 pole spaces, 3 phase, 4 wire, 240VAC, 48VDC
NQ442L4C
| Panelboard Type | Main lugs |
|---|---|
| Product or Component Type | Interiors |
| Branch Circuit Breaker Type | QOB QOB-VH QHB |
| Busbar Material | Copper |
| Number of spaces | 42 |
|---|---|
| Enclosure Nominal Height | 50 in (1270.0000000000 mm) |
| Enclosure Nominal Width | 20 in (508.0000000000 mm) |
| Enclosure Nominal Depth | 5.75 in (146.05 mm) NEMA 1 6.5 in (165.10 mm) NEMA 3R/5/12 |
| Line Rated Current | 400 A |
| [Iu] rated interrupted current | 10 kA 22 kA 65 kA |
| Number of Phases | 3 phase 4 wires |
| Voltage Rating | 240 V AC 48 V DC |
| Connections – terminals | Lug line AWG 1/0…750 kcmil aluminium Lug neutral AWG 1/0…750 kcmil aluminium |
| Tightening torque | 274.99…300.04 lbf.in (31.07…33.90 N.m) 0.08…0.6 in² (53.48…380 mm²) (AWG 1/0…750 kcmil) 274.99…300.04 lbf.in (31.07…33.90 N.m) 0.08…0.3 in² (53.48…177.3 mm²) (AWG 1/0…350 kcmil) 549.98 lbf.in (62.14 N.m) 0.08…0.6 in² (53.48…380 mm²) (AWG 1/0…750 kcmil) 549.98 lbf.in (62.14 N.m) 0.08…0.2 in² (53.48…152 mm²) (AWG 1/0…300 kcmil) 375.006 lbf.in (42.37 N.m) 0.08…0.6 in² (53.48…380 mm²) (AWG 1/0…750 kcmil) 375.006 lbf.in (42.37 N.m) 0.08…0.2 in² (53.48…152 mm²) (AWG 1/0…300 kcmil) |
| Height | 45 in (1143.0000000000 mm) |
| Width | 10.44 in (265.18 mm) |
| Net Weight | 26.65 lb(US) (12.09 kg) |
| Standards | CSA UL |
|---|
| Category | US1PE1A09151 |
|---|---|
| Discount Schedule | PE1A |
| GTIN | 785901507918 |
| Returnability | Yes |
| Country of origin | US |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 6.5 in (16.5 cm) |
| Package 1 Width | 14.02 in (35.6 cm) |
| Package 1 Length | 50.0000000000 in (127.0 cm) |
| Package 1 Weight | 21.751 lb(US) (9.866 kg) |
| Unit Type of Package 2 | PAL |
| Number of Units in Package 2 | 15 |
| Package 2 Height | 40.0000000000 in (101.6 cm) |
| Package 2 Width | 42.0000000000 in (106.68 cm) |
| Package 2 Length | 60.0000000000 in (152.4 cm) |
| Package 2 Weight | 327.00 lb(US) (148.325 kg) |
| Warranty | 18 months |
|---|
| Peso | 5 kg |
|---|---|
| Dimensiones | 15 × 15 × 15 cm |
| Marcas | Schneider Electric |
